RB2011UiAS-2HnD-IN
The RB2011Ui series is a low-cost multi-port device. Designed for indoor use, and available in different enclosures with a multitude of options.
The RB2011 is powered by RouterOS, a fully featured operating system that has been continuously improved for fifteen years. Dynamic routing, hotspot, firewall, MPLS, VPN, advanced quality of service, load balancing and bonding, real-time configuration and monitoring are just some of the vast features of RouterOS.
RouterBOARD 2011UiAS-2HnD tiene la mayoría de las características e interfaces de todos nuestros routers inalámbricos. Está dotado del nuevo procesador de red Atheros 600MHz 74K MIPS, tiene una memoria RAM 128Mb, cinco puertos LAN, cinco puertos LAN Fast Ethernet y caja SFP (módulo SFP no incluido!). También, cuenta con potentes AP inalámbricos 802.11bgn de 1000mW dual chain 2.4Ghz, puerto serial RJ45, puerto micro USB, y una licencia RouterOS nivel 5, así como una caja de sobremesa con fuente de alimentación, dos antenas 4dBi Omni y un panel LCD.
Tested and recommended for use with Mikrotik SFP modules: S-85DLC05D, S-31DLC20D and S-35/53LC20D (not included)
The RouterBOARD 2011UAS-2HnD-IN comes with a desktop case, LCD panel and power supply.
The RB2011Ui also has a passive PoE output on its last port. This means that you can power another device just by connecting it with a regular Ethernet cable.
Product specifications
| DETAILS | |
|---|---|
| Product code | RB2011UiAS-2HnD-IN |
| 10/100 Ethernet ports | 5 |
| 10/100/1000 Ethernet ports | 5 |
| 802.11a | Yes |
| 802.11b | Yes |
| 802.11g | Yes |
| 802.11n | Yes |
| Antenna gain | 4 |
| CPU | AR9344 |
| CPU core count | 1 |
| CPU nominal frequency | 600 MHz |
| Dimensions | 214mm x 86mm for PCB |
| License level | 5 |
| Max Power consumption | 11W |
| Number of USB ports | 1 |
| Number of chains | 2 |
| Operating System | RouterOS |
| PCB temperature monitor | Yes |
| PoE in | Yes |
| PoE out | Yes |
| Power Jack | 1 |
| SFP DDMI | Yes |
| SFP ports | 1 |
| Serial port | RJ45 |
| Size of RAM | 128 MB |
| Storage size | 128 MB |
| Storage type | NAND |
| Supported input voltage | 8 V – 30 V |
| Tested ambient temperature | -35C to 65C |
| USB Power Reset | Yes |
| USB slot type | microUSB type AB |
| Voltage Monitor | Yes |
| Wireless chip model | AR9344 |
| Wireless standards | 802.11b/g/n |
